GS 750 Exhaust question

[one_civic]

Hey Guys, I have a 78 GS 750 and have been looking for a 4-1 exhaust for a while now but without much luck.

Please correct me if I'm wrong but from what I have read is that a GS 850 with VM carbs 4-1 exhaust will fit but not one with CV carbs?

Also can someone clarify that a 4-1 exhaust header from a 1000 will fit but not the tail section?

So my question is, who has used or modified a 1000 4-1 exhaust to fit a 750? Where there any clearance issues on the head pipe? I assume that I will have to modify the rear or fabricate a hanger for the tail section, but that's not a problem.

Cheers



[Spiff]

i have a harris 4-1 on my gs, those where originally made for the 1000/1100 gs's. Head pipes fit, but because the 1000 engine is taller than the 7/850 engines they hang lower than stock. Haven't had any issues myself but other's have reported clearance issues, I also have some scrapes and small dents on the underside of the collector from previous owners hitting stuff but myself I haven't experienced that.



[Josue_Rodz]

the's a MAC 4-1 on ebay for 750s but it's aftermarket, not sure if you were looking for that.



[one_civic]

Thanks Spiff for the info, Josue I'd rather have my baffle less exhaust than a Mac system.



[Chuck78]

You can make different baffles & tail pipes for MAC headers ya know... I did this on mine. I have a Vance & Hines 750/850 exhaust now. I don't think the head makes a difference on the fit of a 79 850 exhaust and 80+ CV carb head 850 exhaust fitment.

Marving makes my favorite gs750 exhaust ever. Flat collector, upswept road pipe with long smaller diameter tailpipe like an old Yoshi, & minimal baffle. $500 & import duties from the UK or Italy.
Motad or someone else in the UK makes two different stainless 750 exhausts also. JAG posted a link a while back.



[Chuck78]

[TABLE="width: 100%"]
[TR]
[TD]GS750D/850GN/T/X 1977-1980 Motad 4-1 Full System Exhaust (Product Code: MOTM7S/2)[/TD]
[TD="align: right"]

[/TD]
[/TR]
[/TABLE]

MOTAD COLLECTORS / PIPEWORK

Motad collectors/pipework are interchangeable with original silencer(s) and are made from Grade 304 stainless steel. A top quality rustproof solution.

NOTE: You have selected a product that will only fit a Suzuki GS750 DB-DC 77-78



[Chuck78]

[TD="class: descr"]PREDATOR 4-1 STAINLESS STEEL EXHAUST SYSTEM ROAD LEGAL
FITS ALL GS750 Models

ALL MODELS ALL YEARS
MANUFACTURED IN 300 SERIES POLISHED STAINLESS STEEL
MANUFACTURERS 10 YEAR WARRANTY
*Note due to age of bike we make this system to order in house takes 7 - 14 Working days *
NO RE-JETTING
RETAINS ALL STANDS
RETAINS ACCESS TO OIL FILTER
FLAT COLLECTOR FOR MAX GROUND CLEARANCE
GREAT LOOKS AND SOUND



[/TD]

[TABLE="class: product-properties"]
[TR]
[TD="class: property-name"]SKU[/TD]
[TD="class: property-value, colspan: 2"]PS31[/TD]
[/TR]
[TR="class: prod_quantity_r"]
[TD="class: property-name"]Quantity in stock[/TD]
[TD="class: property-value product-quantity-text, colspan: 2"]1 item(s) available[/TD]
[/TR]
[TR]
[TD="class: property-name"]Weight[/TD]
[TD="class: property-value, colspan: 2"]25.00 lbs[/TD]
[/TR]
[TR]
[TD="class: poptions-product-separator, colspan: 3"][/TD]
[/TR]
[TR]
[TD="class: property-name product-price"]Our price:[/TD]
[TD="class: property-value, colspan: 2"]?350.00 (€525.34)[/TD]
[/TR]
[TR]
[TD="colspan: 3"][/TD]
[/TR]
[TR="class: quantity-row"]
[TD="class: property-name product-input"]Quantity (1 available)[/TD]
[TD="class: property-value, colspan: 2"] 1 [/TD]
[/TR]
[/TABLE]



[Chuck78]

Harris Works Exhaust on highly modded 77-79 gs750 with quite an odd seat



[Chuck78]

These are still kicking around NOS

Jardine Exhaust Muffler System Suzuki GS750 Thru 1979 GS850 Thru 1981.
Part #: 3800BL, 22-3006



[Chuck78]

My all time favorite, wish I had one of these Marving S/07/BC upswept GS750 road racing pipes:

1977-1979 GS750
4/1 Racing complete S/07/BC system chromium plated NON homologated

They also make a Marving S/3504/BC flat collector megaphone style system for our bikes:

4/1 Master complete system chromium plated silenced NON homologated



[Grimly]

[TABLE="width: 100%"]
[TR]
[TD]GS750D/850GN/T/X 1977-1980 Motad 4-1 Full System Exhaust (Product Code: MOTM7S/2)[/TD]
[TD="align: right"]

[/TD]
[/TR]
[/TABLE]

MOTAD COLLECTORS / PIPEWORK

Motad collectors/pipework are interchangeable with original silencer(s) and are made from Grade 304 stainless steel. A top quality rustproof solution.

NOTE: You have selected a product that will only fit a Suzuki GS750 DB-DC 77-78

These are truly excellent systems. Both mine have them fitted, and I was lucky enough to pick up one of them as remaindered NOS. No doubt about them lasting - more than 20 years on, there's not a crack or corrosion anywhere.
